Cleanroom Pass Throughs: Stainless Steel, Mechanical Interlocks, Mounting Trim Kit, CAP-18W-SST

Cleanroom Pass Throughs - Stainless Steel - Mechanical Interlock - Mounting Trim Kit - CAP-18W-SST

The cleanroom pass through is for transferring of parts and equipment in and out of a cleanroom or controlled environment. They reduce the need for people to enter the cleanroom. The pass through is available in polypropylene or stainless steel construction. The polypropylene pass thru is constructed of 1/2" material and a good choice for use around chemicals. The stainless steel pass thru features a welded type 304 shell, stainless steel continuous hinge, tempered safety glass viewing window, silicon bulb gasket, stainless steel lever and compression door latch. Options available on the pass throughs include: mechanical door interlocks, mounting frame, Lexan window, non-outgassing, and HEPA filtered models.

CLEANROOM PASS THROUGH STANDARD SIZES
•   12"W x 12"H x 12"D
•   18"W x 18"H x 18"D
•   24"W x 24"H x 24"D
•   30"W x 30"H x 30"D
•   36"W x 36"H x 36"D
•   46"W x 46"H x 30"D

CLEANROOM PASS THROUGH FEATURES
•  Stainless steel pass thru body - type 304, #4 finish, 18 gauge
•  Stainless steel pass thru doors - type 304, #4 finish, 16 gauge
•  Stainless steel continuous flush-mount hinges
•  Clear tempered safety glass viewing pass through windows
•  No foam
•  Silicone bulb gasket
•  Type 316 stainless steel lever compression door latches
•  Mechanical interlock
•  Mounting Frame - 8 pc mounting & trim, standard mount, inside finish both sets, type 304, #4 stainless steel, 18 GA
•  Formed and stitch-welded type 304 #4 finish stainless steel construction
•  Formed type 304 #4 finish stainless steel door frames

CLEANROOM PASS THROUGH WEIGHTS (actual weight - not shipping weight)
•  12x12x12   49 lbs.
•  18x18x18   86 lbs.
•  24x24x24   131 lbs.
•  30x30x30   207 lbs.
•  36x36x36   273 lbs.

CLEANROOM PASS THROUGH OPTIONAL UPGRADES

• Material: Type 316L #2b finish stainless steel
                Electropolished type 316L #2 finish stainless steel
                Electropolished type 304 #4 finish stainless steel


• Window Options: Clear wire safety glass
                            Clear laminated safety glass
                            Clear PVC
                            Electrostatic dissipative (ESD) polycarbonate
                            Clear polycarbonate
                            Clear acrylic
                            Yellow acrylic
                            Ultra-violet light filtering acrylic
                            No window - solid stainless steel


• Interlock Options: Mechanical interlock, stainless steel T-handle
                             Internal mount magnetic interlock (increase width by 3", requires a 120 volt power supply)


• Mounting Options: 8 piece stainless steel mounting frame
                             8 piece stainless steel flush-style mounting frame
                             8 piece stainless steel sloped top mounting frame
                             Stainless steel support gussets
                             Stainless steel support legs


• Shelf Options: Solid stainless steel fixed location, removeable shelf
                        Perforated stainless steel fixed location, removeable shelf
                        Solid stainless steel non-adjustable set-in shelf
                        Perforated stainless steel non-adjustable set-in shelf
                        Stainless steel catch tray


• Latch Options: Key locking stainless steel lever compression door latches


• Electrical Options: Duplex receptacle with stainless steel cover
                             UV light without timed shut off
                             UV light with timed shut off
                             Door position indicator lights


• Design Options: Ventilation couplings
                          Low outgassing design

The stainless steel wall mount pass through features a door design that complies with the cleaning requirements of USP800. The enhanced design features an easily cleaned stainless steel door assembly with a silicone bulb gasket. The stainless steel door has a large safety glass viewing window with a heavy gauge stainless steel continuous hinge that is welded to the door and screws to the pass thru body.

Product Code: CAP18W-SST  Stainless Steel Pass Throughs, Tempered Safety Glass Windows, 8 Trim Kit, Mechanical Interlock, Type 304 Stainless Steel

For more options, see our section for stainless steel pass-throughs for cleanrooms and labs.

Visit our main section for lab and cleanroom pass throughs, chambers, boxes, and windows.

TO ORDER STAINLESS STEEL PASS THROUGHS
To order the stainless steel pass throughs, click tab above, call customer service at (303) 752-0076 or email sales@cleanroomworld.com

Shipping Instructions: The stainless steel pass through price does not include freight. The pass through ships on a motor freight carrier and the cost of shipping will be added to your order or can ship collect. Specify the carrier and account number in the box at checkout. Call customer service if a freight quote is required before the pass through is shipped. Indicate to customer service if your facility will require a lift gate or if you have a dock high receiving area. Please include delivery point of contact name and phone number.
